Ceramic Porous Filter Media (BPT) Tile Specification

Shape
Round

Outlet Diameter
5 Inch (in)

Usage
Industrial

Material
Other

Size
Standard

Product Type
Ceramic Porous Filter Media (BPT)

Color
Blue

Width
305x305x35THK Millimeter (mm)

Application
Industrial

Ceramic Porous Filter Media (BPT) Tile Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
50 Pieces Per Day

Delivery Time
7 Days

About Ceramic Porous Filter Media (BPT) Tile

	Blue Porous Media	White Porous Media
Material	Fused Alumina	Aluminosilic ate
Chemical nature	Amphoteric	Amphoteric
AI2O3 content (typical)	82%
Bulk density (max)	2.3 gm/ cm3	2.2 gm/ cm3
Max use temperature	900 deg C	900 deg C
Oxidation/ Reduction effect	Nil	Nil
Reaction with acids	Mild attack by aqua regia/ or HF	Mild attack by aqua regia/ or HF
Reaction with Alkalise	Very slight with very strong hot solution	Very slight with very strong hot solution
Permeability	15-18 cfm/ft2/ inch flow of air at 75 deg F and 25% humidity	15-18 cfm/ft2/ inch flow of air at 75 deg F and 25% humidity
Porosity	30%-40%	25%-35%
Max Particle retention	>25	>25
Modulus of rupture
Dry	150 kgs/ cm2	90 kgs/ cm2
Wet	120 kgs/ cm2	75 kgs/ cm2
Resistance to heat	Excellent	Excellent

Blue Porous Tiles ( Filteration application)
Size : 305*305*25 and 35mmThk. BLUE.
Bentonite PWA Filteration Plate

Advanced Filtration Technology

Crafted from premium ceramic, the BPT Tile offers enhanced filtration capabilities. Its porous structure efficiently traps contaminants, ensuring cleaner outputs in various industrial processes. The 5-inch outlet is optimized for stable flow rates, while the durable build supports extended use and minimal maintenance.

Versatile Industrial Utility

This filter media is suitable for a wide spectrum of industrial applications, including chemical processing, water treatment, and air purification. Thanks to its robust construction and standardized design, the tile integrates easily into existing systems, enhancing operational safety and efficiency.

FAQ's of Ceramic Porous Filter Media (BPT) Tile:

Q: How is the Ceramic Porous Filter Media (BPT) Tile typically used in industrial settings?

A: The Ceramic Porous Filter Media (BPT) Tile is installed in filtration systems to remove particulate matter and impurities from liquids or gases. Its porous ceramic construction enables effective filtration, making it suitable for processes such as water treatment, chemical processing, and air purification.

Q: What benefits does the 5-inch outlet diameter provide for industrial applications?

A: The 5-inch outlet diameter ensures an optimal balance of flow rate and filtration efficiency. It allows sufficient throughput while maintaining the integrity of the filtration process, making it suitable for high-demand industrial systems.

Q: When should the filter media tile be replaced during operation?

A: Replacement timing depends on the specific usage conditions and contaminant load. Typically, the tile should be replaced when there is a noticeable drop in flow rate or an increase in pressure across the filter, indicating that the pores are becoming clogged.

Q: Where can the Ceramic Porous Filter Media (BPT) Tile be sourced in India?

A: This product is available through authorized distributors, exporters, manufacturers, suppliers, and traders throughout India. It can be ordered directly from industrial supply companies specializing in filtration solutions.

Q: What is the process of installing the Ceramic Porous Filter Media Tile?

A: Installation involves integrating the tile into the filtration system's housing, aligning its 305x305x35 mm frame and connecting the 5-inch outlet. Proper sealing and support should be ensured to prevent bypass and maximize filtration efficiency.

Q: How does the blue color of the tile benefit users?

A: The blue color facilitates easy identification and maintenance checks within industrial environments, reducing the chance of mix-ups and streamlining inspection processes.
